| Onderdeel nommer | ATNA56WR06-0 |
| Handelsmerk | SAMSUNG |
| Grootte | 15.6 |
| Toepassing | Laptop |
| Resolusie | 3840×2160 |
| Samestelling | AM-OLED, OLED |
| Helderheid | |
| CR | 100000:1 |
| Kleure | 1.06B |
| Agterlig | self |
| Koppelvlak | eDP |
| paneel handelsmerk | SAMSUNG |
| paneel model | ATNA56WR06-0 |
| paneel grootte | 15.6" |
| paneel tipe | AM-OLED, OLED |
| resolusie | 3840(RGB)×2160, UHD, 283PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 344.218(W)×193.622(H) mm |
| ring opening | - |
| omtrek grootte | 348.218(W)×215.572(H) ×2.2(D) mm |
| oppervlak | Glare (Haze 0%) |
| helderheid | 440 cd/m² (Typ.) |
| kontras verhouding | 100000:1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| vertoonmodus | - |
| beste uitsig op | Symmetry |
| reaksie tyd | 1 (Typ.)(Tr+Tf) |
| kleure vertoon | 1.06B 100% DCI-P3 |
| tipe lamp | self |
| frekwensie | 60Hz |
| raakskerm | Without |
| vorm styl | Slim (PCBA Flat, T≤3.2mm) |
| aansoek | Laptop |
| sein koppelvlak | eDP (4 Lanes) , eDP1.4b , HBR2 (5.4G/lane) , 40 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -40 ~ 85 °C |
