| Onderdeel nommer | AT043TN14 V.1 |
| Handelsmerk | Innolux |
| Grootte | 4.3 |
| Toepassing | Portable Navigation |
| Resolusie | 480×272 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | Parallel |
| handelsmerk | Innolux |
| model | AT043TN14 V.1 |
| diagonale grootte | 4.3 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 480(RGB)×272 [WQVGA] 128PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 95.04(H)×53.856(V) mm |
| buitelyn dof. | - |
| ring area | - |
| behandeling | Antiglare |
| helderheid | - |
| kontras verhouding | 500:1 (Typ.) (TM) |
| kyk rigting | 6 o'clock |
| reaksie tyd | 10/15 (Typ.)(Tr/Td) |
| kykhoek | 70/70/50/70 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 16.7M |
| Ligbron | WLED |
| gewig | - |
| ontwerp vir | Portable Navigation MP3 PMP |
| raamkoers | - |
| raakpaneel | 4-wire Resistive Touch |
| koppelvlak tipe | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| kragtoevoer | (2.5/3.3)/5.0V (Typ.)(VDD/AVDD) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
