| Onderdeel nommer | AM800480R3TMQW-B2H |
| Handelsmerk | AMPIRE |
| Grootte | 7.0 |
| Toepassing | Industrial |
| Resolusie | 800×480 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 400:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | AMPIRE |
| model | AM800480R3TMQW-B2H |
| diagonale grootte | 7.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 800(RGB)×480 [WVGA] 133PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 152.4(H)×91.44(V) mm |
| buitelyn dof. | - |
| helderheid | - |
| kontras verhouding | 400:1 (Typ.) (TM) |
| kyk rigting | 6 o'clock |
| reaksie tyd | 5/11 (Typ.)(Tr/Td) |
| kykhoek | 70/70/60/70 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 262K 45% NTSC |
| Ligbron | WLED |
| gewig | - |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (1 ch, 8-bit) , 20 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| B070EAN01.6 | AUO | 7.0 | 800×1280 |
| BP070WX1-300 | BOE | 7.0 | 800×1280 |
| CLAA070VA01 | CPT | 7.0 | 800×480 |
| HJ070NA-13A | Innolux | 7.0 | 1024×600 |
| HSD070IDW1-D00 | HannStar | 7.0 | 800×480 |
| LD070WS2-SL01 | LG Display | 7.0 | 1024×600 |
| LQ070Y3DG02 | SHARP | 7.0 | 800×480 |
| LQ070Y3LG4A | SHARP | 7.0 | 800×480 |
| P070BAG-CM1 | Innolux | 7.0 | 1024×600 |
| PW070NS1W2 | E Ink | 7.0 | 480×320 |
