| Onderdeel nommer | AM480272H3TMQW-TW1H |
| Handelsmerk | AMPIRE |
| Grootte | 4.3 |
| Toepassing | Industrial |
| Resolusie | 480×272 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 250:1 |
| Kleure | 65K/262K |
| Agterlig | WLED |
| Koppelvlak | 8/9/16/18-bit |
| handelsmerk | AMPIRE |
| model | AM480272H3TMQW-TW1H |
| diagonale grootte | 4.3 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 480(RGB)×272 [WQVGA] 128PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 95.04(H)×53.856(V) mm |
| buitelyn dof. | 105.5(H)×67.2(V) ×7.91(D) mm |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 250:1 (Typ.) (TM) |
| kyk rigting | 6 o'clock |
| reaksie tyd | 15/35 (Typ.)(Tr/Td) |
| kykhoek | 70/70/35/55 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 65K/262K 52% NTSC |
| Ligbron | WLED [7S1P] , 15K hours , W/O Driver |
| gewig | TBD |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | 4-wire Resistive Touch |
| koppelvlak tipe | 8/9/16/18-bit 6800/8080 parallel , 40 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
