| Onderdeel nommer | AM1024600K7TMQW-T62H |
| Handelsmerk | AMPIRE |
| Grootte | 7.0 |
| Toepassing | Industrial |
| Resolusie | 1024×600 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 700:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | AMPIRE |
| paneel grootte | 7.0" |
| resolusie | 1024(RGB)×600, WSVGA, 169PPI |
| vertoon area | 153.6(W)×90(H) mm |
| helderheid | - |
| kykhoek | 75/75/70/75 (Typ.)(CR≥10) |
| beste uitsig op | - |
| kleure vertoon | 262K/16.7M |
| frekwensie | 60Hz |
| gewig | - |
| paneel model | AM1024600K7TMQW-T62H |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| kontras verhouding | 700:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 20/20 (Typ.)(Tr/Td) |
| tipe lamp | WLED |
| raakskerm | PCAP |
| aansoek | Industrial |
| A070FW01 | AUO | 7.0 | 480×234 |
| C070VW02 V0 | AUO | 7.0 | 800×480 |
| EDTCB18QEF | TOSHIBA | 7.0 | 800×480 |
| G070Y2-T02 | Innolux | 7.0 | 800×480 |
| LB070WV3-SD02 | LG Display | 7.0 | 800×480 |
| LD070WX5-SM01 | LG Display | 7.0 | 900×1440 |
| LMS700JF01-001 | Samsung | 7.0 | 1024×600 |
| LQ070Y5DG20 | SHARP | 7.0 | 800×480 |
| LT070ME05000 | JDI | 7.0 | 1200×1920 |
| PM070WX9 | E Ink | 7.0 | 800×480 |
