| Onderdeel nommer | AM-800600MTMQW-50H |
| Handelsmerk | AMPIRE |
| Grootte | 8.4 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 800×600 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 600:1 |
| Kleure | 262K/16.7M |
| Agterlig | 6S5P |
| Koppelvlak | |
| paneel handelsmerk | AMPIRE |
| paneel grootte | 8.4" |
| resolusie | 800(RGB)×600, SVGA, 119PPI |
| vertoon area | 170.4(W)×127.8(H) mm |
| omtrek grootte | 189.75(W)×149.4(H) ×5.3(D) mm |
| helderheid | 1000 cd/m² (Typ.) |
| kykhoek | 75/75/60/70 (Typ.)(CR≥10) |
| beste uitsig op | - |
| kleure vertoon | 262K/16.7M |
| frekwensie | 60Hz |
| gewig | TBD |
| paneel model | AM-800600MTMQW-50H |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 173.4(W)×130.8(H) mm |
| oppervlak | - |
| kontras verhouding | 600:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 8 (Typ.)(Tr+Td) |
| tipe lamp | 6S5P WLED , Without Driver |
| raakskerm | Without |
| aansoek | Industrial Outdoor High Brightness |
| AA084SA01 | Mitsubishi | 8.4 | 800×600 |
| AM-800600M3TNQW-00H | AMPIRE | 8.4 | 800×600 |
| AM-800600M3TNQW-01H-F | AMPIRE | 8.4 | 800×600 |
| G084SN05 V3 | AUO | 8.4 | 800×600 |
| G084SN05 V7 | AUO | 8.4 | 800×600 |
| LQ084S3LG03 | SHARP | 8.4 | 800×600 |
| LTA084C190F | TOSHIBA | 8.4 | 800×600 |
| LTA084C274F | TOSHIBA | 8.4 | 800×600 |
| NL6448BC26-08D | NLT | 8.4 | 640×480 |
| NL6448BC26-09C | NLT | 8.4 | 640×480 |
