| Onderdeel nommer | AM-800600K2TMQW-04H |
| Handelsmerk | AMPIRE |
| Grootte | 10.4 |
| Toepassing | Industrial |
| Resolusie | 800×600 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | AMPIRE |
| paneel grootte | 10.4" |
| resolusie | 800(RGB)×600, SVGA, 96PPI |
| vertoon area | 211.2(W)×158.4(H) mm |
| omtrek grootte | 243(W)×185.6(H) mm |
| helderheid | 500 cd/m² (Typ.) |
| kykhoek | 70/70/50/60 (Typ.)(CR≥10) |
| beste uitsig op | 6 o'clock |
| kleure vertoon | 262K 50% NTSC |
| frekwensie | 60Hz |
| paneel gewig | - |
| sein koppelvlak | LVDS (1 ch, 6-bit) , 20 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -35 ~ 85 °C |
| paneel model | AM-800600K2TMQW-04H |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 214.8(W)×162.7(H) mm |
| oppervlak | - |
| kontras verhouding | 500:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 5/15 (Typ.)(Tr/Td) |
| tipe lamp | WLED , 30K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Industrial |
