| Onderdeel nommer | AM-800480R2TMQW-U0H |
| Handelsmerk | AMPIRE |
| Grootte | 7.0 |
| Toepassing | Industrial |
| Resolusie | 800×480 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 250:1 |
| Kleure | 65K |
| Agterlig | WLED |
| Koppelvlak | UART |
| vervaardiger | AMPIRE |
| model naam | AM-800480R2TMQW-U0H |
| skerm grootte | 7.0 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 800(RGB)×480 (WVGA) 133PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 152.4 × 91.44 (H×V) |
| buitelyn (mm) | 178.5 × 110 × 20.4 (H×V×D) |
| ring area (mm) | 155.3 × 94.3 (H×V) |
| behandeling | - |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 250 : 1 (Typ.) (TM) |
| kykhoek | 70/70/60/60 (Typ.)(CR≥10) |
| reaksie | 50 (Typ.)(Tr+Td) ms |
| goeie uitsig by | - |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | 65K 48% NTSC |
| agterlig | WLED , With LED Driver |
| massa | - |
| gebruik vir | Industrial |
| herlaaitempo | - |
| raakskerm | Without |
| sein tipe | UART , 8 pins Connector |
| spanningstoevoer | 4.6/26.0V (Min./Typ.) |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
