| Onderdeel nommer | AM-800480N3TZQW-57H |
| Handelsmerk | AMPIRE |
| Grootte | 5.0 |
| Toepassing | Industrial Automotiv |
| Resolusie | 800×480 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 262K |
| Agterlig | 3S6P |
| Koppelvlak | |
| vervaardiger | AMPIRE |
| model naam | AM-800480N3TZQW-57H |
| skerm grootte | 5.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 800(RGB)×480 (WVGA) 188PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 108 × 64.8 (H×V) |
| buitelyn (mm) | 119.7 × 78.3 × 10.05 (H×V×D) |
| ring area (mm) | 109.6 × 66.4 (H×V) |
| behandeling | - |
| helderheid | 1000 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 262K |
| agterlig | 3S6P WLED , 50K hours , With LED Driver |
| massa | - |
| gebruik vir | Industrial Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
