| Onderdeel nommer | AM-800480L6TZQW-TN0H-I |
| Handelsmerk | AMPIRE |
| Grootte | 5.0 |
| Toepassing | Industrial |
| Resolusie | 800×480 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 250:1 |
| Kleure | 16.7M |
| Agterlig | 3S4P |
| Koppelvlak | Parallel |
| vervaardiger | AMPIRE |
| model naam | AM-800480L6TZQW-TN0H-I |
| skerm grootte | 5.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 800(RGB)×480 (WVGA) 188PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 108 × 64.8 (H×V) |
| buitelyn (mm) | 118.5 × 77.1 × 6.44 (H×V×D) |
| ring area (mm) | 110.6 × 67.4 (H×V) |
| behandeling | - |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 250 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 15/35 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | Normally Black, Transmissive |
| kleurdiepte | 16.7M 52% NTSC |
| agterlig | 3S4P WLED , 30K hours , No Driver |
| massa | - |
| gebruik vir | Industrial |
| herlaaitempo | 60Hz |
| raakskerm | PCAP |
| sein tipe | Parallel RGB (1 ch, 8-bit) , FPC 45 pins |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
