| Onderdeel nommer | AM-800480BDTZQW-00H |
| Handelsmerk | AMPIRE |
| Grootte | 4.3 |
| Toepassing | Industrial Automotiv |
| Resolusie | 800×480 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 700:1 |
| Kleure | 16.2M |
| Agterlig | WLED |
| Koppelvlak | Parallel |
| handelsmerk | AMPIRE |
| model | AM-800480BDTZQW-00H |
| diagonale grootte | 4.3 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 800(RGB)×480 [WVGA] 216PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 95.04(H)×53.856(V) mm |
| buitelyn dof. | 105.3(H)×67(V) mm |
| ring area | 97.9(H)×56.7(V) mm |
| behandeling | - |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 700:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 40 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedryfsmodus | Normally Black, Transmissive |
| ondersteun kleur | 16.2M |
| Ligbron | WLED [6S2P] , 50K hours , W/O Driver |
| gewig | - |
| ontwerp vir | Industrial Automotive Display |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
