| Onderdeel nommer | AM-800480BCTMQW-T00H |
| Handelsmerk | AMPIRE |
| Grootte | 5.0 |
| Toepassing | Industrial |
| Resolusie | 800×480 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 600:1 |
| Kleure | 16.7M |
| Agterlig | 6S2P |
| Koppelvlak | Parallel |
| vervaardiger | AMPIRE |
| skerm grootte | 5.0 inch |
| pixel nommer | 800(RGB)×480 (WVGA) 188PPI |
| aktiewe area (mm) | 108 × 64.8 (H×V) |
| helderheid | 340 cd/m² (Typ.) |
| kykhoek | 75/75/60/70 (Typ.)(CR≥10) |
| goeie uitsig by | 6 o'clock |
| kleurdiepte | 16.7M 52% NTSC |
| massa | - |
| herlaaitempo | 60Hz |
| sein tipe | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| model naam | AM-800480BCTMQW-T00H |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 129.9 × 86.7 × 7.18 (H×V×D) |
| kontras verhouding | 600 : 1 (Typ.) (TM) |
| reaksie | 4/12 (Typ.)(Tr/Td) ms |
| werksmodus | TN, Normally White, Transmissive |
| agterlig | 6S2P WLED , 50K hours , No Driver |
| gebruik vir | Industrial |
| raakskerm | PCAP |
| C050FTN01.0 | AUO | 5.0 | 480×234 |
| EJ050NA-01G | Innolux | 5.0 | 800×480 |
| G050VTN01.1 | AUO | 5.0 | 800×480 |
| H495TAN01.1 | AUO | 5.0 | 720×1280 |
| HSD050FMW2-D00 | HannStar | 5.0 | 540×960 |
| HSD050I9W1-A00 | HannStar | 5.0 | 480×272 |
| LM050QC1T01 | SHARP | 5.0 | 320×240 |
| LMS500HF06 | Samsung | 5.0 | 480×272 |
| LQ050A5BS01 | SHARP | 5.0 | 320×234 |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
