| Onderdeel nommer | AM-800480AZTMQW-05H |
| Handelsmerk | AMPIRE |
| Grootte | 5.0 |
| Toepassing | Industrial |
| Resolusie | 800×480 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 600:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | AMPIRE |
| model | AM-800480AZTMQW-05H |
| diagonale grootte | 5.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 800(RGB)×480 [WVGA] 188PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 108(H)×64.8(V) mm |
| buitelyn dof. | 118.5(H)×77.1(V) ×7.41(D) mm |
| ring area | 110.6(H)×67.4(V) mm |
| behandeling | - |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 600:1 (Typ.) (TM) |
| kyk rigting | - |
| reaksie tyd | 2/6 (Typ.)(Tr/Td) |
| kykhoek | 75/75/70/60 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 262K 47% NTSC |
| Ligbron | WLED [3S7P] , 30K hours , With LED Driver |
| gewig | - |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | Without |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
