| Onderdeel nommer | AM-480272MGTZQW-02H |
| Handelsmerk | AMPIRE |
| Grootte | 4.3 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 480×272 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | 5S3P |
| Koppelvlak | Parallel |
| paneel handelsmerk | AMPIRE |
| paneel model | AM-480272MGTZQW-02H |
| paneel grootte | 4.3" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 480(RGB)×272, WQVGA, 128PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 95.04(W)×53.856(H) mm |
| ring opening | 97.6(W)×56.0(H) mm |
| omtrek grootte | 105.6(W)×67.2(H) ×3.1(D) mm |
| oppervlak | - |
| helderheid | 1000 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kleure vertoon | 16.7M 51% NTSC |
| tipe lamp | 5S3P WLED , Without Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | - |
| aansoek | Industrial Outdoor High Brightness Automotive Display |
| sein koppelvlak | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
