| Onderdeel nommer | AM-480272HBTMQW-T00H |
| Handelsmerk | AMPIRE |
| Grootte | 4.3 |
| Toepassing | Industrial |
| Resolusie | 480×272 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 250:1 |
| Kleure | 16.7M |
| Agterlig | 7S1P |
| Koppelvlak | Parallel |
| vervaardiger | AMPIRE |
| model naam | AM-480272HBTMQW-T00H |
| skerm grootte | 4.3 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 480(RGB)×272 (WQVGA) 128PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 95.04 × 53.856 (H×V) |
| buitelyn (mm) | 105.5 × 67.2 × 7.99 (H×V×D) |
| ring area (mm) | 98.7 × 57.5 (H×V) |
| behandeling | - |
| helderheid | 250 cd/m² (Typ.) |
| kontras verhouding | 250 : 1 (Typ.) (TM) |
| kykhoek | 65/65/45/45 (Typ.)(CR≥10) |
| reaksie | 40 (Typ.)(Tr+Td) ms |
| goeie uitsig by | 6 o'clock |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | 16.7M |
| agterlig | 7S1P WLED , 20K hours , No Driver |
| massa | - |
| gebruik vir | Industrial |
| herlaaitempo | 60Hz |
| raakskerm | PCAP |
| sein tipe | Parallel RGB (1 ch, 8-bit) , FPC 54 pins |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
