| Onderdeel nommer | AM-240320GTZQW-02H |
| Handelsmerk | AMPIRE |
| Grootte | 2.8 |
| Toepassing | Mobile Phone |
| Resolusie | 240×320 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 450:1 |
| Kleure | 65K |
| Agterlig | WLED |
| Koppelvlak | CPU/RGB/SPI |
| handelsmerk | AMPIRE |
| model | AM-240320GTZQW-02H |
| diagonale grootte | 2.8 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 240(RGB)×320 [QVGA] 141PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 43.2(H)×57.6(V) mm |
| buitelyn dof. | 49(H)×67.5(V) ×4.9(D) mm |
| helderheid | 280 cd/m² (Typ.) |
| kontras verhouding | 450:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 15/20 (Typ.)(Tr/Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedryfsmodus | MVA, Normally Black, Transmissive |
| ondersteun kleur | 65K 69% NTSC |
| Ligbron | WLED [3S2P] , With LED Driver |
| gewig | TBD |
| ontwerp vir | Mobile Phone |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | CPU/RGB/SPI , 40 pins FPC |
| kragtoevoer | 2.8V (Typ.) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AM-240320-022F | Other | 2.2 | 240×320 |
| AM-240320-024DT | Other | 2.4 | 240×320 |
| C0283QGLD-T | CMEL | 2.8 | 240×320 |
| ET028002DMU | EDT | 2.8 | 240×320 |
| F-55472GNFJ-SLW-AAN | Kyocera | 2.8 | 128×64 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LTV280QV-F02 | Samsung | 2.8 | 320×240 |
| TD028STEB1 | TPO | 2.8 | 240×320 |
| TFT240320-237-E | Other | 2.8 | 240×320 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
