| Onderdeel nommer | AM-19201200CTZQW-T01 |
| Handelsmerk | AMPIRE |
| Grootte | 10.1 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1920×1200 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | AMPIRE |
| model | AM-19201200CTZQW-T01 |
| diagonale grootte | 10.1 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1920(RGB)×1200 [WUXGA] 225PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 216.576(H)×135.36(V) mm |
| buitelyn dof. | 244.8(H)×155.3(V) ×8.01(D) mm |
| helderheid | 850 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | AHVA, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 49% NTSC |
| Ligbron | WLED [7S6P] , 50K hours , W/O Driver |
| gewig | - |
| ontwerp vir | Industrial Outdoor High Brightness |
| raamkoers | 60Hz |
| raakpaneel | PCAP |
| Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -20 ~ 65 °C |
