| Onderdeel nommer | AM-19201200CTZQW-00 |
| Handelsmerk | AMPIRE |
| Grootte | 10.1 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1920×1200 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| vervaardiger | AMPIRE |
| model naam | AM-19201200CTZQW-00 |
| skerm grootte | 10.1 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1920(RGB)×1200 (WUXGA) 225PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 216.576 × 135.36 (H×V) |
| buitelyn (mm) | 244.8 × 155.3 × 7 (H×V×D) |
| helderheid | 1000 cd/m² (Typ.) |
| kontras verhouding | 800 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | AHVA, Normally Black, Transmissive |
| kleurdiepte | 16.7M 49% NTSC |
| agterlig | WLED , 50K hours , With LED Driver |
| massa | - |
| gebruik vir | Industrial Outdoor High Brightness |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -20 ~ 65 °C Operating Temp.: -20 ~ 65 °C |
| AM-19201200B1TZQW-T00 | AMPIRE | 10.1 | 1920×1200 |
| BP101WX1-400 | BOE | 10.1 | 1280×800 |
| CLAA101WA01A | CPT | 10.1 | 1366×768 |
| HSD100IFW1-A04 | HannStar | 10.1 | 1024×600 |
| HSD100IFW1-F03 | HannStar | 10.1 | 1024×600 |
| LP101WS1-TLA1 | LG Display | 10.1 | 1024×576 |
| LTN101AL03-801 | Samsung | 10.1 | 1280×800 |
| N101BCG-GK1 | Innolux | 10.1 | 1366×768 |
| N101BGE-L21 | Innolux | 10.1 | 1366×768 |
| N101N6-L01 | Innolux | 10.1 | 1024×576 |
