| Onderdeel nommer | AM-1280800N2TZQW-T28H |
| Handelsmerk | AMPIRE |
| Grootte | 10.1 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1280×800 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | 7S6P |
| Koppelvlak | |
| paneel handelsmerk | AMPIRE |
| paneel grootte | 10.1" |
| resolusie | 1280(RGB)×800, WXGA, 149PPI |
| vertoon area | 216.96(W)×135.6(H) mm |
| omtrek grootte | 247(W)×166(H) ×8.95(D) mm |
| helderheid | 850 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 45% NTSC |
| frekwensie | 60Hz |
| gewig | 413g (Typ.) |
| paneel model | AM-1280800N2TZQW-T28H |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 220.76(W)×140.4(H) mm |
| oppervlak | - |
| kontras verhouding | 800:1 (Typ.) (TM) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| tipe lamp | 7S6P WLED , 50K hours , Without Driver |
| raakskerm | PCAP |
| aansoek | Industrial Outdoor High Brightness |
