| Onderdeel nommer | AM-1024768V1TZQW-A0H |
| Handelsmerk | AMPIRE |
| Grootte | 8.4 |
| Toepassing | Industrial |
| Resolusie | 1024×768 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | AMPIRE |
| model | AM-1024768V1TZQW-A0H |
| diagonale grootte | 8.4 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1024(RGB)×768 [XGA] 152PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 170.8(H)×128.1(V) mm |
| buitelyn dof. | 203(H)×145.5(V) ×8(D) mm |
| ring area | 174.15(H)×131.2(V) mm |
| behandeling | - |
| helderheid | 1000 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | IPS, Normally Black, Transmissive |
| ondersteun kleur | 16.7M |
| Ligbron | WLED [6S6P] , 50K hours , With LED Driver |
| gewig | - |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (1 ch, 8-bit) , 20 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
