| Onderdeel nommer | AM-1024768TTMQW-T00H |
| Handelsmerk | AMPIRE |
| Grootte | 10.4 |
| Toepassing | Industrial |
| Resolusie | 1024×768 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 900:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | AMPIRE |
| model | AM-1024768TTMQW-T00H |
| diagonale grootte | 10.4 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1024(RGB)×768 [XGA] 123PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 211.2(H)×158.4(V) mm |
| buitelyn dof. | 236(H)×176.9(V) ×7.9(D) mm |
| ring area | 214.8(H)×162.0(V) mm |
| behandeling | Antiglare |
| helderheid | 280 cd/m² (Typ.) |
| kontras verhouding | 900:1 (Typ.) (TM) |
| kyk rigting | 6 o'clock |
| reaksie tyd | 16 (Typ.)(Tr+Td) |
| kykhoek | 75/75/75/75 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 262K/16.7M |
| Ligbron | WLED [4 strings] , 30K hours , With LED Driver |
| gewig | 290g (Max.) |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | 4-wire Resistive Touch |
| koppelvlak tipe | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
