| Onderdeel nommer | AM-1024768R3TNQW-T00H |
| Handelsmerk | AMPIRE |
| Grootte | 12.1 |
| Toepassing | Industrial |
| Resolusie | 1024×768 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | AMPIRE |
| model | AM-1024768R3TNQW-T00H |
| diagonale grootte | 12.1 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1024(RGB)×768 [XGA] 105PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 245.76(H)×184.32(V) mm |
| buitelyn dof. | 279(H)×209(V) ×11.2(D) mm |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| kyk rigting | - |
| reaksie tyd | 16 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 262K/16.7M |
| Ligbron | WLED , 30K hours , With LED Driver |
| gewig | - |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | PCAP |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
