| Onderdeel nommer | AM-1024600LHMQW-16H |
| Handelsmerk | AMPIRE |
| Grootte | 10.1 |
| Toepassing | Industrial |
| Resolusie | 1024×600 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K |
| Agterlig | 6S6P |
| Koppelvlak | LVDS |
| vervaardiger | AMPIRE |
| model naam | AM-1024600LHMQW-16H |
| skerm grootte | 10.1 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 1024(RGB)×600 (WSVGA) 117PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 222.72 × 125.28 (H×V) |
| buitelyn (mm) | 235 × 145.8 × 7.3 (H×V×D) |
| ring area (mm) | 225.92 × 128.48 (H×V) |
| behandeling | Antiglare |
| helderheid | 250 cd/m² (Typ.) |
| kontras verhouding | 500 : 1 (Typ.) (TM) |
| kykhoek | 70/70/70/50 (Typ.)(CR≥10) |
| reaksie | 4/12 (Typ.)(Tr/Td) ms |
| goeie uitsig by | - |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | 262K 47% NTSC |
| agterlig | 6S6P WLED , 20K hours , With LED Driver |
| massa | TBD |
| gebruik vir | Industrial |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (1 ch, 6-bit) , 30 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
