| Onderdeel nommer | AM-1024600K8TMQW-T09H |
| Handelsmerk | AMPIRE |
| Grootte | 7.0 |
| Toepassing | Industrial |
| Resolusie | 1024×600 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 700:1 |
| Kleure | 16.7M |
| Agterlig | 5S3P |
| Koppelvlak | |
| vervaardiger | AMPIRE |
| model naam | AM-1024600K8TMQW-T09H |
| skerm grootte | 7.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1024(RGB)×600 (WSVGA) 169PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 153.6 × 90 (H×V) |
| buitelyn (mm) | 165.5 × 104.4 × 10.77 (H×V×D) |
| ring area (mm) | - |
| behandeling | Glare (Haze 0%), Hard coating |
| helderheid | 425 cd/m² (Typ.) |
| kontras verhouding | 700 : 1 (Typ.) (TM) |
| kykhoek | 75/75/70/75 (Typ.)(CR≥10) |
| reaksie | 20/20 (Typ.)(Tr/Td) ms |
| goeie uitsig by | 6 o'clock |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | 16.7M |
| agterlig | 5S3P WLED , 30K hours , With LED Driver |
| massa | TBD |
| gebruik vir | Industrial |
| herlaaitempo | 60Hz |
| raakskerm | PCAP |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
