| Onderdeel nommer | AM-1024600K7TMQW-T19H |
| Handelsmerk | AMPIRE |
| Grootte | 7.0 |
| Toepassing | Industrial |
| Resolusie | 1024×600 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 700:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | AMPIRE |
| diagonale grootte | 7.0 inch |
| pixel formaat | 1024(RGB)×600 [WSVGA] 169PPI |
| aktiewe area | 153.6(H)×90(V) mm |
| helderheid | 425 cd/m² (Typ.) |
| kyk rigting | 6 o'clock |
| kykhoek | 75/75/70/75 (Typ.)(CR≥10) |
| ondersteun kleur | 16.7M |
| gewig | TBD |
| raamkoers | 60Hz |
| model | AM-1024600K7TMQW-T19H |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 165.5(H)×104.44(V) ×10.81(D) mm |
| kontras verhouding | 700:1 (Typ.) (TM) |
| reaksie tyd | 20/20 (Typ.)(Tr/Td) |
| bedryfsmodus | TN, Normally White, Transmissive |
| Ligbron | WLED [5S3P] , 30K hours , With LED Driver |
| ontwerp vir | Industrial |
| raakpaneel | PCAP |
| 70WVW1A | SII | 7.0 | 800×480 |
| 70WVW1T | SII | 7.0 | 800×480 |
| A070VW08 V0 | AUO | 7.0 | 800×480 |
| A070XN01 V0 | AUO | 7.0 | 1024×768 |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AT070TN92 V.3 | Innolux | 7.0 | 800×480 |
