| Onderdeel nommer | AM-1024600ITZQW-00H |
| Handelsmerk | AMPIRE |
| Grootte | 10.1 |
| Toepassing | Industrial |
| Resolusie | 1024×600 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | AMPIRE |
| paneel model | AM-1024600ITZQW-00H |
| paneel grootte | 10.1" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1024(RGB)×600, WSVGA, 117PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 222.72(W)×125.28(H) mm |
| ring opening | - |
| omtrek grootte | 234.9(W)×143(H) ×4.9(D) mm |
| oppervlak | Antiglare, Hard coating |
| helderheid | 550 cd/m² (Typ.) |
| kontras verhouding | 500:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 12/28 (Typ.)(Tr/Td) |
| kleure vertoon | 262K/16.7M 70% NTSC |
| tipe lamp | WLED , 50K hours , Without Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | - |
| aansoek | Industrial |
| sein koppelvlak | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| insetspanning | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| omgewing | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
