| Onderdeel nommer | AM-1024600DTZQW-TA6H |
| Handelsmerk | AMPIRE |
| Grootte | 7.0 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1024×600 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | AMPIRE |
| model | AM-1024600DTZQW-TA6H |
| diagonale grootte | 7.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1024(RGB)×600 [WSVGA] 170PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 154.221(H)×85.92(V) mm |
| buitelyn dof. | 164.9(H)×128(V) ×12.6(D) mm |
| helderheid | 850 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 13/15 (Typ.)(Tr/Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | IPS, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 58% NTSC |
| Ligbron | WLED , 50K hours , With LED Driver |
| gewig | - |
| ontwerp vir | Industrial Outdoor High Brightness |
| raamkoers | 60Hz |
| raakpaneel | PCAP |
| koppelvlak tipe | LVDS (1 ch, 8-bit) , 20 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
