| Onderdeel nommer | AM-1024600DTZQW-TA0H |
| Handelsmerk | AMPIRE |
| Grootte | 7.0 |
| Toepassing | Industrial |
| Resolusie | 1024×600 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | AMPIRE |
| paneel grootte | 7.0" |
| resolusie | 1024(RGB)×600, WSVGA, 170PPI |
| vertoon area | 154.221(W)×85.92(H) mm |
| omtrek grootte | 184(W)×128(H) ×12.6(D) mm |
| helderheid | 425 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 58% NTSC |
| frekwensie | 60Hz |
| gewig | - |
| paneel model | AM-1024600DTZQW-TA0H |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | - |
| kontras verhouding | 800:1 (Typ.) (TM) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| reaksie tyd | 13/15 (Typ.)(Tr/Td) |
| tipe lamp | WLED , 30K hours , With LED Driver |
| raakskerm | PCAP |
| aansoek | Industrial |
