| Onderdeel nommer | AM-1024600DTZQW-A6H |
| Handelsmerk | AMPIRE |
| Grootte | 7.0 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1024×600 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| vervaardiger | AMPIRE |
| model naam | AM-1024600DTZQW-A6H |
| skerm grootte | 7.0 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 1024(RGB)×600 (WSVGA) 170PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 154.221 × 85.92 (H×V) |
| buitelyn (mm) | 164.9 × 100 (H×V×D) |
| ring area (mm) | 158 × 89.7 (H×V) |
| behandeling | Antiglare |
| helderheid | 1000 cd/m² (Typ.) |
| kontras verhouding | 800 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 13/15 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 16.7M |
| agterlig | WLED , 50K hours , With LED Driver |
| massa | - |
| gebruik vir | Industrial Outdoor High Brightness |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (1 ch, 8-bit) , 20 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
