| Onderdeel nommer | AC101TB01 |
| Handelsmerk | Mitsubishi |
| Grootte | 10.1 |
| Toepassing | Industrial |
| Resolusie | 1280×800 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.2M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | Mitsubishi |
| model | AC101TB01 1 Compatible |
| diagonale grootte | 10.1 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1280(RGB)×800 [WXGA] 149PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 216.96(H)×135.6(V) mm |
| buitelyn dof. | 231(H)×153.5(V) ×10.25(D) mm |
| ring area | - |
| behandeling | Antiglare |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | - |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | SWV, Normally Black, Transmissive |
| ondersteun kleur | 16.2M 50% NTSC |
| Ligbron | WLED , 50K hours , With LED Driver |
| gewig | - |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | Without |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -20 ~ 70 °C |
