| Onderdeel nommer | AA190EA01 |
| Handelsmerk | Mitsubishi |
| Grootte | 19.0 |
| Toepassing | IA |
| Resolusie | 1280×1024 |
| Samestelling | LCM |
| Helderheid | 1500 |
| CR | 800:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | Mitsubishi |
| paneel model | AA190EA01 1 Compatible model |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 19.0 inch |
| resolusie | 1280(RGB)×1024 , SXGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 376.32×301.056 mm |
| buitelyn | 404.2×330×15.4 mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 1500 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) |
| kleure vertoon | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| reaksie tyd | 4/12 (Typ.)(Tr/Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 4 strings × 2CNWLEDWithout Driver |
| sein koppelvlak | LVDS (2 ch, 6/8-bit), 30 pins |
| insetspanning | 5.0V (Typ.) |
| aansoek | IA |
