| Onderdeel nommer | AA106TA01DDE11 |
| Handelsmerk | Mitsubishi |
| Grootte | 10.6 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1280×768 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | Mitsubishi |
| model | AA106TA01DDE11 |
| diagonale grootte | 10.6 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1280(RGB)×768 [WXGA] 140PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 231.36(H)×138.816(V) mm |
| buitelyn dof. | 250(H)×175(V) ×15.5(D) mm |
| ring area | - |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 800 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 12/12 (Typ.)(Tr/Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | SWV, Normally Black, Transmissive |
| ondersteun kleur | 262K/16.7M 50% NTSC |
| Ligbron | WLED , 100K hours , With LED Driver |
| gewig | 670g (Typ.) |
| ontwerp vir | Industrial Outdoor High Brightness |
| raamkoers | 60Hz |
| raakpaneel | PCAP |
| Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AA106TA01 | Mitsubishi | 10.6 | 1280×768 |
| LQ106K1LA01C | SHARP | 10.6 | 1280×768 |
| LQ106K1LA02 | SHARP | 10.6 | 1280×768 |
| LQ106K1LA05 | SHARP | 10.6 | 1280×768 |
| LTD106EWNN | TOSHIBA | 10.6 | 1280×768 |
| LTL106AL01-001 | Samsung | 10.6 | 1366×768 |
| LTL106HL01-001 | Samsung | 10.6 | 1920×1080 |
| LTN106W1-L01 | Samsung | 10.6 | 1280×768 |
| LTN106W2-L01 | Samsung | 10.6 | 1280×768 |
