| Onderdeel nommer | AA101TA12 |
| Handelsmerk | Mitsubishi |
| Grootte | 10.1 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1280×800 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 262K/16.7M |
| Agterlig | 2 |
| Koppelvlak | LVDS |
| paneel handelsmerk | Mitsubishi |
| paneel grootte | 10.1" |
| resolusie | 1280(RGB)×800, WXGA, 149PPI |
| vertoon area | 216.96(W)×135.6(H) mm |
| omtrek grootte | 231(W)×153.5(H) ×9(D) mm |
| helderheid | 800 cd/m² (Typ.) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 262K/16.7M 50% NTSC |
| frekwensie | 60Hz |
| paneel gewig | 310g |
| sein koppelvlak | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -40 ~ 80 °C ; Storage Temp.: -40 ~ 80 °C |
| paneel model | AA101TA12 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 220.96(W)×139.6(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | SWV, Normally Black, Transmissive |
| reaksie tyd | 12/12 (Typ.)(Tr/Td) |
| tipe lamp | 2 strings WLED , 100K hours , Without Driver |
| raakskerm | Without |
| aansoek | Industrial Outdoor High Brightness |
| AA104SG01 | Mitsubishi | 10.4 | 800×600 |
| AA104SG04 | Mitsubishi | 10.4 | 800×600 |
| AA104SH02 | Mitsubishi | 10.4 | 800×600 |
| AA104SH02--T1 | Mitsubishi | 10.4 | 800×600 |
| AA104VB04 | Mitsubishi | 10.4 | 640×480 |
| AA104VC04 | Mitsubishi | 10.4 | 640×480 |
| AA104VC10 | Mitsubishi | 10.4 | 640×480 |
| AA104VH01 | Mitsubishi | 10.4 | 640×480 |
| AA104XD12--G1 | Mitsubishi | 10.4 | 1024×768 |
| AA104XG12 | Mitsubishi | 10.4 | 1024×768 |
