| Onderdeel nommer | AA070TA01 |
| Handelsmerk | Mitsubishi |
| Grootte | 7.0 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1280×768 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | Mitsubishi |
| paneel grootte | 7.0" |
| resolusie | 1280(RGB)×768, WXGA, 214PPI |
| vertoon area | 151.68(W)×91.01(H) mm |
| omtrek grootte | 169.8(W)×109.7(H) mm |
| helderheid | 1000 cd/m² (Typ.) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 262K/16.7M 49% NTSC |
| frekwensie | 60Hz |
| gewig | 200g (Typ.) |
| paneel model | AA070TA01 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 155.1(W)×94.4(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | SWV, Normally Black, Transmissive |
| reaksie tyd | 12/12 (Typ.)(Tr/Td) |
| tipe lamp | WLED , 100K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Industrial Outdoor High Brightness Automotive Display |
| AA070MC01 | Mitsubishi | 7.0 | 800×480 |
| AA070MC11 | Mitsubishi | 7.0 | 800×480 |
| AA070ME01 | Mitsubishi | 7.0 | 800×480 |
| AA070ME01-DA1 | Mitsubishi | 7.0 | 800×480 |
| AA078AA01 | Mitsubishi | 7.8 | 800×300 |
| B070EAN01.6 | AUO | 7.0 | 800×1280 |
| HSD070IDW1-A00 | HannStar | 7.0 | 800×480 |
| HSD070IDW1-A30 | HannStar | 7.0 | 800×480 |
| LW700AT9008 | Innolux | 7.0 | 800×480 |
| TFD70W11-F1 | TOSHIBA | 7.0 | 480×234 |
