| Onderdeel nommer | A084SN01 V1 |
| Handelsmerk | AUO |
| Grootte | 8.4 |
| Toepassing | GM |
| Resolusie | 800×600 |
| Samestelling | LCM |
| Helderheid | 420 |
| CR | 350:1 |
| Kleure | 262K |
| Agterlig | CCFL |
| Koppelvlak | TTL |
| paneel handelsmerk | AU Optronics |
| paneel model | A084SN01 V1 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 8.4 inch |
| resolusie | 800(RGB)×600 , SVGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 170.4×127.8 mm |
| buitelyn | 199.8×150 mm |
| oppervlak | |
| helderheid | 420 cd/m² (Typ.) |
| kontras verhouding | 350:1 (Typ.) |
| kleure vertoon | 262K (6-bit) |
| reaksie tyd | 10/25 (Typ.)(Tr/Td) |
| kykhoek | 65/65/45/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | CCFLEmbedded (Inverter) |
| sein koppelvlak | Parallel RGB (1 ch, 6-bit), 36 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | GM |
