| Onderdeel nommer | A050EAT01.0 |
| Handelsmerk | AUO |
| Grootte | 5.0 |
| Toepassing | Industrial |
| Resolusie | 1280×720 |
| Samestelling | a-Si TFT-LCD, Assemb |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | MIPI |
| handelsmerk | AUO |
| model | A050EAT01.0 |
| diagonale grootte | 5.0 inch |
| tipe | a-Si TFT-LCD, Assembly |
| pixel formaat | 1280×720(RGB) [WXGA] 294PPI |
| konfigurasie | RGB Horizontal Stripe |
| aktiewe area | 110.4(H)×62.1(V) mm |
| buitelyn dof. | 136.38(H)×91.71(V) ×4.86(D) mm |
| helderheid | 800 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 20/15 (Typ.)(Tr/Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedryfsmodus | - |
| ondersteun kleur | 16.7M 66% NTSC |
| Ligbron | WLED [7S3P] , W/O Driver |
| gewig | 63g (Typ.) |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | PCAP |
| koppelvlak tipe | MIPI (4 data lanes) , 42 pins Connector |
| kragtoevoer | 1.8/3.3V (Typ.)(VDDI/VCI) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
